Overall Dimensions Overall width 1060 mm Overall height 2300 mm Overall length 3800 mm Mini ground clearance 230 mm Ground contact length of track 1090 mm Track width 230 mm Track gauge 820 mm Bucket capacity 0.06 m³ Operating range Boom length 3470 mm Arm length 3560 mm Max digging reach 2150 mm Max digging depth 3275 mm Max digging height 2310 mm Max dumping height 1740 mm Mini swing radius 1440 mm Rear swing radius 285 mm Max ground digging range 195 mm Max vertical digging depth 1500 mm Specification Unit Operating weight 1960kgs Engine Model 3TNV74 Rated power 14.6KW/2400rpm Hydraulic system 20Mpa Swing system 10rpm Travel speed 0-4.5km/h Bucket digging force 14KN Arm digging force 10KN Grade ability <35°(70%) Ground pressure 30KPa
